Some notes on how to capture network packets in a .pcap format, so you can feed your hungry Wireshark.

cover

Packets don’t lie. ― Laura Chappell

Quick Access

Linux

tcpdump is one of the best tools to capture network traffic. It is included with several Linux distributions, so chances are you do not need to bother with any installations.

To capture network packets in any interface and store the results in a trace.pcap file, just open your favourite Terminal and type as follows:

sudo tcpdump -i any -w trace.pcap

Note that if you want to capture the packets in a specific interface, you can find all the available interfaces by executing the following command:

sudo tcpdump -D

Mac

Similarly to Linux distros, MacOS has tcpdump as built-in packet trace tool.

To capture network packets in any interface and store the results in a trace.pcap file, just open your favourite Terminal and type as follows:

sudo tcpdump -i any -w trace.pcap

Note that if you want to capture the packets in a specific interface, you can find all the available interfaces by executing the following command:

sudo tcpdump -D

Alternatively, you can also determine the correct interface name by running the networksetup command-line tool with the -listallhardwareports argument. This prints a list of network interfaces also including a user-visible name.

$ networksetup -listallhardwareports


Hardware Port: Ethernet
Device: en0
Ethernet Address: 54:45:5b:01:ca:89


Hardware Port: Wi-Fi
Device: en1
Ethernet Address: 78:a1:3c:02:2b:da


… and so on …

Windows

QuickPcap.ps1 is a quick and easy PowerShell script to collect a packet trace in a .etl format. Note that you need to download the latest etl2pcapng to convert the trace to a .pcap format.

Further information can be found in this article, where the author explains all the details.

<#
QuickPcap.ps1
https://github.com/dwmetz
Author: @dwmetz
Function: This script will use the native functions on a Windows host to collect a packet capture as an .etl file.
Note the secondary phase where etl2pcapng is required to convert to pcap.
#>

# Get the local IPv4 address
$env:HostIP = (
    Get-NetIPConfiguration |
    Where-Object {
        $_.IPv4DefaultGateway -ne $null -and
        $_.NetAdapter.Status -ne "Disconnected"
    }
).IPv4Address.IPAddress

# Capture until the specified Sleep duration (default: 90s)
netsh trace start capture=yes IPv4.Address=$env:HostIP tracefile=c:\temp\capture.etl
Start-Sleep 90
netsh trace stop

# Convert .etl to .pcap
Set-Location C:\Tools\etl2pcapng\x64
./etl2pcapng.exe c:\temp\capture.etl c:\temp\capture.pcap
Set-Location C:\Temp
Get-ChildItem

To execute QuickPcap.ps1 just open a PowerShell and type as follows:

File_Location\QuickPcap.ps1

Note that this script considers the active interface by default (stored in $env:HostIP). If you want to use a specific interface, you need to change the $env:HostIP variable with the IPv4 address of such interface. To list all available interfaces, you can execute the following command:

Ipconfig /all
